GFC0612DS-AQ14
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL DUAL 60X56MM 12VDC
PDF
/
Inventory: 7562
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Weight 0.359lb 162.84g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2010
Series GFC
Size / Dimension Square - 60mm Lx60mm H
Feature PWM Control, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads per Fan
Power (Watts) 19.2W
Voltage - Rated 12VDC
Current Rating (Amps) 1.6A
Approval Agency CE, UR, VDE
Lifetime @ Temp 50000 Hrs @ 40°C
RPM 10400 Front, 9500 Rear
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Air Flow 65.0 CFM (1.82m3/min)
Noise 66.0 dB(A)
Voltage Range 10.8V~13.2VDC
Static Pressure 2.007 in H2O (499.9 Pa)
Dimensions
Width 56.00mm
Compliance
RoHS Status ROHS3 Compliant
