GFC0412DS-CMA5
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
40X40X56MM 12V DC FAN WITH SPEED SENSOR (TACH) AND PWM SPEED
PDF
/
Inventory: 3840
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.176lb 79.83g
Material - Frame Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2010
Series GFC
Size / Dimension Square - 40mm Lx40mm H
Feature PWM Control, Speed Sensor (Tach)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads per Fan
Voltage - Rated 12VDC
Current Rating (Amps) 0.850A
Max Power Dissipation 10.2W
Current Rating 850mA
Approval Agency CE, cURus, TUV
Lifetime @ Temp 30000 Hrs @ 55°C
Life (Hours) 30000 hours
RPM 17200 Front, 15700 Rear
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Air Flow 25.3 CFM (0.708m3/min)
Noise 64.0 dB(A)
Voltage Range 10.8V~12.6VDC
Static Pressure 2.703 in H2O (673.3 Pa)
Compliance
RoHS Status ROHS3 Compliant
