GFB0412VHF-F00
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL DUAL 40X32MM 12VDC
PDF
/
Inventory: 9522
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case Axial
Weight 0.099lb 44.91g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2004
Series GFB
Size / Dimension Rectangular - 40mm Lx50mm H
Feature Speed Sensor (Tach)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads per Fan
Voltage - Rated 12VDC
Additional Feature REAR FAN SPEED: 9100, APPROVALS: UL; VDE
Power Rating 4.32W
Current Rating (Amps) 0.360A
Max Power Dissipation 4.32W
Depth 40mm
Reach Compliance Code unknown
Current Rating 360mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
Speed 9500 rpm
RPM 9500 Front, 9100 Rear
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Air Flow 19.7 CFM (0.552m3/min)
Noise 51.5 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.554 in H2O (138.0 Pa)
Thermal Support Device Type DC FAN
Dimensions
Length 50mm
Width 32mm
Compliance
RoHS Status RoHS Compliant
