GFB0412EHS-F00

Delta Electronics
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN AXIAL DUAL 40X56MM 12VDC
PDF
/
Inventory: 7947
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case Axial
Weight 0.176lb 79.83g
Material - Frame Plastic

Technical

Published 2003
Series GFB
Size / Dimension Square - 40mm Lx40mm H
Feature Speed Sensor (Tach)
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads per Fan
Max Operating Temperature 60°C
Min Operating Temperature -10°C
Additional Feature REAR FAN SPEED: 11200, APPROVALS: UL; VDE
Power Rating 15W
Voltage - Rated DC 12V
Max Power Dissipation 15W
Depth 40mm
Reach Compliance Code unknown
Current Rating 1.25A
Approval Agency CE, CSA, UL, VDE
Speed 15000 rpm
RPM 15000 Front, 11200 Rear
Bearing Type Ball
Fan Type Tubeaxial (Dual)
Air Flow 27.3 CFM (0.764m3/min)
Noise 59.5 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 1.630 in H2O (406.0 Pa)
Thermal Support Device Type DC FAN

Dimensions

Length 56mm

Compliance

RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
