FFC0912DE-SP13
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X38MM 12VDC WIRE
PDF
/
Inventory: 3618
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.408lb 185.07g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2007
Series FFC
Size / Dimension Square - 92mm Lx92mm H
Feature PWM Control, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads
Max Operating Temperature 140°C
Min Operating Temperature 14°C
Power (Watts) 10.6W
Voltage - Rated 12VDC
Current Rating (Amps) 0.880A
Max Power Dissipation 10.6W
Current Rating 880mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 5000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 103.8 CFM (2.91m3/min)
Noise 55.0 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.681 in H2O (169.6 Pa)
Dimensions
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
