FFB1424UHE-MF00

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 140X140X38MM 24V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 9283
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Housing Material Plastic
Material - Frame Aluminum
Material - Blade Plastic

Technical

Published 2015
Series FFB
Size / Dimension Square - 140mm Lx140mm H
Feature Speed Sensor (Tach)
Part Status Active
Termination 3 Wire Leads
Power (Watts) 80.4W
Voltage - Rated 24VDC
Power Rating 80.4W
Current Rating (Amps) 3.35A
Approval Agency CE, CSA, UR, VDE
RPM 5500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 367.6 CFM (10.29m3/min)
Noise 74.0 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 1.644 in H2O (409.5 Pa)

Dimensions

Height 140mm
Length 140mm
Width 38.00mm

Compliance

RoHS Status ROHS3 Compliant
