FFB1424UHE-M
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 24V 3.35A 80.4W 5500RPM 367.62CFM 74dB Flange Mount
PDF
/
Inventory: 2504
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges
Package / Case Axial
Housing Material Plastic
Weight 1.4lbs 635g
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series FFB
Size / Dimension Square - 139.7mm Lx139.7mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Max Operating Temperature 158°C
Min Operating Temperature 14°C
Power (Watts) 80.4W
Voltage - Rated 24VDC
Power Rating 80.4W
Current Rating (Amps) 3.35A
Max Power Dissipation 80.4W
Current Rating 3.35A
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 80000 Hrs @ 40°C
RPM 5500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 367.6 CFM (10.29m3/min)
Noise 74.0 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 1.644 in H2O (409.5 Pa)
Dimensions
Height 139.7mm
Length 139.7mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
