FFB1324SHE-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
127X127X38MM 24V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 3823
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Published 2015
Series FFB
Size / Dimension Square - 127mm Lx127mm H
Feature Locked Rotor Sensor
Part Status Active
Termination 3 Wire Leads
Power (Watts) 20.16W
Voltage - Rated 24VDC
Power Rating 20.16W
Current Rating (Amps) 0.840A
Approval Agency CE, CSA, UR, VDE
RPM 3450 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 180.0 CFM (5.04m3/min)
Noise 56.5 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 0.642 in H2O (160.0 Pa)
Dimensions
Height 127mm
Length 127mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
