FFB1324EHE
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 127X38MM 24VDC WIRE
PDF
/
Inventory: 7009
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 127mm
Technical
Static Pressure 0.799 in H2O (199.0 Pa)
Voltage Range 14V~26.4VDC
Noise 59.5 dB(A)
Air Flow 200.0 CFM (5.60m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3850 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 1.2A
Reach Compliance Code unknown
Depth 127mm
Max Power Dissipation 28.8W
Current Rating (Amps) 1.20A
Power Rating 28.8W
Voltage - Rated 24VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension Square - 127mm Lx127mm H
Series FFB
Physical
Material - Frame Plastic
Weight 1lb 453.59g
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
