FFB1248XHE-M
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 48V 1.65A 79.2W 6300RPM 264.62CFM 73.5dB Flange Mount
PDF
/
Inventory: 8521
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges
Package / Case Axial
Housing Material Aluminium
Weight 1.102lb 500.0g
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2005
Series FFB
Size / Dimension Square - 120mm Lx120mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 48VDC
Power Rating 79.2W
Max Power Dissipation 79.2W
Depth 120mm
Reach Compliance Code unknown
Current Rating 1.65A
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 6300 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 264.6 CFM (7.41m3/min)
Noise 73.5 dB(A)
Voltage Range 28V~54VDC
Static Pressure 1.705 in H2O (424.7 Pa)
Thermal Support Device Type DC FAN
Dimensions
Height 120mm
Compliance
RoHS Status ROHS3 Compliant
