FFB1248SH
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Ball Bearing 48V 0.25A 12W 3700RPM 140.16CFM 54.3dB Flange Mount
PDF
/
Inventory: 3295
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2012
Series FFB
Size / Dimension Square - 120mm Lx120mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 12W
Voltage - Rated 48VDC
Power Rating 12W
Current Rating (Amps) 0.250A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3700 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 140.0 CFM (3.92m3/min)
Noise 54.3 dB(A)
Voltage Range 28V~53VDC
Static Pressure 0.419 in H2O (104.4 Pa)
Dimensions
Height 120mm
Length 120mm
Width 25.40mm
Compliance
RoHS Status ROHS3 Compliant
