FFB1224SHE-R00
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
120X120X38MM 24V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Buying Options
Total Price: USD $31.53
Unit Price: USD $31.526689
≥1 USD $31.526689
≥10 USD $29.74216
≥100 USD $28.058635
≥500 USD $26.470411
≥1000 USD $24.972088
Inventory: 1138
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.816lb 370.13g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2005
Series FFB
Size / Dimension Square - 120mm Lx120mm H
Feature Locked Rotor Sensor
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Voltage - Rated 24VDC
Power Rating 19.2W
Current Rating (Amps) 0.800A
Max Power Dissipation 19.2W
Reach Compliance Code unknown
Current Rating 800mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 3600 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 170.9 CFM (4.79m3/min)
Noise 56.5 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 0.563 in H2O (140.2 Pa)
Thermal Support Device Type DC FAN
Dimensions
Height 120mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
