FFB1224EH-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
120X120X25.4MM 24V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 8732
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Plastic
Weight 0.452lb 205.02g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2014
Series FFB
Size / Dimension Square - 120mm Lx120mm H
Feature Locked Rotor Sensor
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Max Operating Temperature 140°C
Min Operating Temperature 14°C
Power (Watts) 15.1W
Voltage - Rated 24VDC
Power Rating 15.12W
Current Rating (Amps) 0.630A
Max Power Dissipation 15.1W
Current Rating 630mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 4000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 150.3 CFM (4.21m3/min)
Noise 56.4 dB(A)
Voltage Range 14V~26.4VDC
Static Pressure 0.489 in H2O (121.9 Pa)
Dimensions
Height 120mm
Length 120mm
Width 25.40mm
Compliance
RoHS Status ROHS3 Compliant
