FFB1224EH
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Axial Ball Bearing 24V 14V to 26.4V 150.33CFM 56.4dB( 120 X 120 X 25.4mm)
PDF
/
Inventory: 5265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 120mm
Technical
Static Pressure 0.489 in H2O (121.9 Pa)
Voltage Range 14V~26.4VDC
Noise 56.4 dB(A)
Air Flow 150.3 CFM (4.21m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4000 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 630mA
Depth 120mm
Max Power Dissipation 15.1W
Current Rating (Amps) 0.630A
Power Rating 15.12W
Voltage - Rated 24VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 120mm Lx120mm H
Series FFB
Published 2011
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.452lb 205.02g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
