FFB1212EHE-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
120X120X38MM 12V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 6715
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series FFB
Size / Dimension Square - 120mm Lx120mm H
Feature Locked Rotor Sensor
Part Status Active
Termination 3 Wire Leads
Power (Watts) 24W
Voltage - Rated 12VDC
Current Rating (Amps) 2.00A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 4000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 190.0 CFM (5.32m3/min)
Noise 59.0 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.700 in H2O (174.4 Pa)
Dimensions
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
