FFB0948SHE-TP28
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 92X38MM 48VDC WIRE
PDF
/
Buying Options
Total Price: USD $22.39
Unit Price: USD $22.391236
≥1 USD $22.391236
≥10 USD $21.123809
≥100 USD $19.928118
≥500 USD $18.80012
≥1000 USD $17.735961
Inventory: 1084
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Weight 0.436lb 197.77g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2009
Series FFB
Size / Dimension Square - 92mm Lx92mm H
Feature PWM Control, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 4 Wire Leads
Voltage - Rated 48VDC
Power Rating 9.6W
Current Rating (Amps) 0.200A
Max Power Dissipation 9.6W
Reach Compliance Code unknown
Current Rating 200mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 4400 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 100.3 CFM (2.81m3/min)
Noise 52.5 dB(A)
Voltage Range 32V~56VDC
Static Pressure 0.572 in H2O (142.5 Pa)
Dimensions
Height 92mm
Compliance
RoHS Status ROHS3 Compliant
