FFB0948SHE
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FFB Series 4400 RPM 92 x 92 x 38 mm 100.29 CFM 48 V Ball Bearing Fan
PDF
/
Inventory: 5978
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Dimensions
Height 92mm
Technical
Static Pressure 0.572 in H2O (142.5 Pa)
Voltage Range 28V~53VDC
Noise 52.5 dB(A)
Air Flow 100.3 CFM (2.81m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4400 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 200mA
Reach Compliance Code unknown
Depth 92mm
Max Power Dissipation 9.6W
Current Rating (Amps) 0.200A
Voltage - Rated DC 48V
Power Rating 9.6W
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension Square - 92mm Lx92mm H
Series FFB
Published 2005
Physical
Material - Frame Plastic
Weight 0.436lb 197.77g
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
