FFB0924HHE-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
92X92X38MM 24V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 4596
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Material - Frame Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2015
Series FFB
Size / Dimension Square - 92mm Lx92mm H
Feature Locked Rotor Sensor
Part Status Active
Termination 3 Wire Leads
Voltage - Rated 24VDC
Power Rating 4.32W
Current Rating (Amps) 0.180A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 71.7 CFM (2.01m3/min)
Noise 42.5 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.298 in H2O (74.2 Pa)
Dimensions
Height 92mm
Compliance
RoHS Status ROHS3 Compliant
