FFB0912EHE-R00
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
92X92X38MM 12V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 1862
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 92mm
Technical
Static Pressure 0.665 in H2O (165.6 Pa)
Voltage Range 7V~13.8VDC
Noise 55.0 dB(A)
Air Flow 110.2 CFM (3.09m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 4800 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 1A
Reach Compliance Code unknown
Max Power Dissipation 12W
Power Rating 12W
Voltage - Rated 12VDC
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Sensor
Size / Dimension Square - 92mm Lx92mm H
Series FFB
Published 2005
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.436lb 197.77g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
Alternative Model
