FFB0848HHE-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
80X80X38MM 48V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 5076
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Series FFB
Size / Dimension Square - 80mm Lx80mm H
Feature Locked Rotor Sensor
Part Status Active
Termination 3 Wire Leads
Power (Watts) 3.84W
Voltage - Rated 48VDC
Power Rating 3.84W
Current Rating (Amps) 0.080A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 3400 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 45.2 CFM (1.27m3/min)
Noise 39.0 dB(A)
Voltage Range 28V~56VDC
Static Pressure 0.281 in H2O (70.0 Pa)
Dimensions
Height 80mm
Length 80mm
Width 38.00mm
Compliance
RoHS Status ROHS3 Compliant
