FFB0848HHE

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Ball Bearing 48V 0.08A 3.84W 3400RPM 45.2CFM 39dB Flange Mount
PDF
/
Inventory: 1981
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 38.00mm
Length 80mm
Height 80mm

Technical

Static Pressure 0.281 in H2O (70.0 Pa)
Voltage Range 28V~56VDC
Noise 39.0 dB(A)
Air Flow 45.2 CFM (1.27m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3400 RPM
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.080A
Power Rating 3.84W
Voltage - Rated 48VDC
Power (Watts) 3.84W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square - 80mm Lx80mm H
Series FFB
Operating Temperature 14~158°F -10°C~70°C

Physical

Material - Blade Plastic
Material - Frame Plastic
Housing Material Plastic

Supply Chain

Factory Lead Time 17 Weeks
