FFB0812UHE-F00
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 80X38MM 12VDC WIRE
PDF
/
Inventory: 8422
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Housing Material Plastic
Weight 0.375lb 170.1g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2004
Series FFB
Size / Dimension Square - 80mm Lx80mm H
Feature Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Max Operating Temperature 158°C
Min Operating Temperature 14°C
Power (Watts) 18W
Voltage - Rated 12VDC
Power Rating 18W
Current Rating (Amps) 1.5A
Max Power Dissipation 18W
Depth 80mm
Current Rating 1.5A
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 50000 Hrs @ 40°C
Life (Hours) 50000 hours
RPM 7500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 102.0 CFM (2.86m3/min)
Noise 62.2 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 1.233 in H2O (307.1 Pa)
Dimensions
Length 80mm
Width 38.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
