FFB0612VHE
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Fan Axial Ball Bearing 12V 4.5V to 13.8V 36.73CFM 46.5dB (60 X 60 X 38mm)
PDF
/
Inventory: 982
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Width 38mm
Technical
Thermal Support Device Type DC FAN
Static Pressure 0.525 in H2O (130.8 Pa)
Voltage Range 4.5V~13.8VDC
Noise 46.5 dB(A)
Air Flow 36.7 CFM (1.03m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 6000 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 340mA
Reach Compliance Code unknown
Depth 60mm
Max Power Dissipation 4.08W
Current Rating (Amps) 0.340A
Voltage - Rated DC 12V
Power Rating 4.08W
Additional Feature APPROVALS: UL; VDE
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension Square - 60mm Lx60mm H
Series FFB
Published 2004
Physical
Material - Frame Plastic
Weight 0.234lb 106.14g
Package / Case Axial
Mount Flanges
