FFB0612EHE

Delta Electronics
RoHS
/
Package Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Axial Ball Bearing 12V 4.5V to 13.8V 50.15CFM 54.5dB (60 X 60 X 38mm)
PDF
/
Inventory: 7415
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Width 38mm

Technical

Thermal Support Device Type DC FAN
Static Pressure 0.972 in H2O (242.1 Pa)
Voltage Range 4.5V~13.8VDC
Noise 54.5 dB(A)
Air Flow 50.2 CFM (1.41m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 8000 RPM
Approval Agency CE, CSA, UL, VDE
Current Rating 800mA
Reach Compliance Code unknown
Depth 60mm
Max Power Dissipation 9.6W
Current Rating (Amps) 0.800A
Voltage - Rated DC 12V
Power Rating 9.6W
Additional Feature APPROVALS: UL; VDE
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension Square - 60mm Lx60mm H
Series FFB
Published 2004

Physical

Material - Frame Plastic
Weight 0.234lb 106.14g
Package / Case Axial
Mount Flanges
