FFB0412MN
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FFB Series 4 0x 40 x 28 mm 12 VDC 5000 RPM 8.05 CFM Ball Bearing Axial Fan
PDF
/
Buying Options
Total Price: USD $13.79
Unit Price: USD $13.7896
≥1 USD $13.7896
≥10 USD $13.15864
≥100 USD $11.905344
≥500 USD $10.965504
≥1000 USD $9.837696
≥3000 USD $9.085754
Inventory: 385
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges
Package / Case Axial
Weight 0.071lb 32.21g
Material - Frame Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2015
Series FFB
Size / Dimension Square - 40mm Lx40mm H
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 600mW
Current Rating (Amps) 0.050A
Max Power Dissipation 600mW
Current Rating 50mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 5000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 8.0 CFM (0.224m3/min)
Noise 30.0 dB(A)
Voltage Range 4.5V~13.8VDC
Static Pressure 0.148 in H2O (37.0 Pa)
Thermal Support Device Type DC FAN
Dimensions
Height 40mm
Width 28mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
