FFB03612EHN-BGA
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 36X28MM 12VDC WIRE
PDF
/
Buying Options
Total Price: USD $12.03
Unit Price: USD $12.030949
≥1 USD $12.030949
≥10 USD $11.349953
≥100 USD $10.707497
≥500 USD $10.101419
≥1000 USD $9.529635
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Static Pressure 1.000 in H2O (249.1 Pa)
Voltage Range 10.8V~13.2VDC
Noise 50.0 dB(A)
Air Flow 16.3 CFM (0.456m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 14500 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 330mA
Reach Compliance Code unknown
Max Power Dissipation 3.96W
Current Rating (Amps) 0.330A
Voltage - Rated 12VDC
Termination 4 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature PWM Control, Speed Sensor (Tach)
Size / Dimension Square - 36mm Lx36mm H
Series FFB
Published 2011
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.071lb 32.21g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
