EFB1724VHG
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 172X50.8MM 24VDC WIRE
PDF
/
Inventory: 5793
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Package / Case Axial
Housing Material Aluminium
Weight 1.9lbs 861.8g
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2005
Series EFB
Size / Dimension Round - 172mm Dia
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 24VDC
Power Rating 23.28W
Current Rating (Amps) 0.970A
Max Power Dissipation 23.3W
Reach Compliance Code unknown
Current Rating 970mA
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 80000 Hrs @ 40°C
Life (Hours) 80000 hours
RPM 4000 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 302.3 CFM (8.46m3/min)
Noise 57.0 dB(A)
Voltage Range 12V~28VDC
Static Pressure 0.937 in H2O (233.4 Pa)
Thermal Support Device Type DC FAN
Dimensions
Height 172mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
