EFB1724MG-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
?172X50.8MM 24V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 5922
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 50.80mm
Length 172mm
Height 172mm
Technical
Static Pressure 0.571 in H2O (142.2 Pa)
Voltage Range 12V~28VDC
Noise 50.0 dB(A)
Air Flow 230.3 CFM (6.45m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3050 RPM
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.470A
Power Rating 11.28W
Voltage - Rated 24VDC
Power (Watts) 11.28W
Termination 3 Wire Leads
Part Status Active
Feature Locked Rotor Sensor
Size / Dimension Round - 172mm Dia
Series EFB
Published 2015
Physical
Material - Blade Plastic
Material - Frame Aluminum
Housing Material Aluminium
