EFB1712MG-F00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
?172X50.8MM 12V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 8442
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 50.80mm
Length 172mm
Height 172mm
Technical
Static Pressure 0.571 in H2O (142.2 Pa)
Voltage Range 8V~14VDC
Noise 50.0 dB(A)
Air Flow 230.3 CFM (6.45m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3050 RPM
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.990A
Power Rating 11.88W
Voltage - Rated 12VDC
Power (Watts) 11.88W
Termination 3 Wire Leads
Part Status Active
Feature Speed Sensor (Tach)
Size / Dimension Round - 172mm Dia
Series EFB
Physical
Material - Blade Plastic
Material - Frame Aluminum
Housing Material Aluminium
Supply Chain
Factory Lead Time 17 Weeks
