EFB1524MG-R00

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 172X150X50.8MM 24V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 3263
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 50.80mm
Length 172mm
Height 150mm

Technical

Static Pressure 0.571 in H2O (142.2 Pa)
Voltage Range 12V~28VDC
Noise 52.0 dB(A)
Air Flow 230.3 CFM (6.45m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 3050 RPM
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.470A
Power Rating 11.28W
Voltage - Rated 24VDC
Power (Watts) 11.28W
Termination 3 Wire Leads
Part Status Active
Feature Locked Rotor Sensor
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Series EFB
Published 2015

Physical

Material - Blade Plastic
Material - Frame Aluminum
Housing Material Aluminium

Supply Chain

Factory Lead Time 17 Weeks
