EFB1524MG
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
172X150X50.8MM 24V DC FAN
PDF
/
Inventory: 1831
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Housing Material Aluminium
Material - Frame Aluminum
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2015
Series EFB
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 11.28W
Voltage - Rated 24VDC
Power Rating 11.28W
Current Rating (Amps) 0.470A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 80000 Hrs @ 40°C
RPM 3050 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 230.3 CFM (6.45m3/min)
Noise 52.0 dB(A)
Voltage Range 12V~28VDC
Static Pressure 0.571 in H2O (142.2 Pa)
Dimensions
Height 150mm
Length 172mm
Width 50.80mm
Compliance
RoHS Status ROHS3 Compliant
