EFB1512HG-R00

Delta Electronics
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description 172X150X50.8MM 12V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 6426
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Housing Material Aluminium
Material - Frame Aluminum
Material - Blade Plastic

Technical

Operating Temperature 14~158°F -10°C~70°C
Published 2015
Series EFB
Size / Dimension Rectangular/Rounded - 172mm Lx150mm H
Feature Locked Rotor Sensor
Part Status Active
Termination 3 Wire Leads
Power (Watts) 16.2W
Voltage - Rated 12VDC
Power Rating 16.2W
Current Rating (Amps) 1.35A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 80000 Hrs @ 40°C
RPM 3350 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 251.8 CFM (7.05m3/min)
Noise 55.0 dB(A)
Voltage Range 8V~14VDC
Static Pressure 0.689 in H2O (171.6 Pa)

Dimensions

Height 150mm
Length 172mm
Width 50.80mm

Compliance

RoHS Status ROHS3 Compliant

Alternative Model
