EFB0812HHB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 80X80X15 MM 12V WIRE
PDF
/
Buying Options
Total Price: USD $11.77
Unit Price: USD $11.7744
≥1 USD $11.7744
≥10 USD $11.23584
≥100 USD $10.166112
≥500 USD $9.363552
≥1000 USD $8.400383
≥3000 USD $7.758326
Inventory: 995
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Weight 0.148lb 67.13g
Material - Frame Plastic
Technical
Published 2015
Series EFB
Size / Dimension Square - 80mm Lx80mm H
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 3.96W
Current Rating (Amps) 0.330A
Max Power Dissipation 3.96W
Reach Compliance Code unknown
Current Rating 330mA
Approval Agency CE, CSA, UL, VDE
RPM 3800 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 48.8 CFM (1.37m3/min)
Noise 41.0 dB(A)
Voltage Range 5V~13.2VDC
Static Pressure 0.171 in H2O (42.6 Pa)
Dimensions
Height 80mm
Compliance
RoHS Status ROHS3 Compliant
