EFB0505HA image
Favorite
EFB0505HA image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description DC Fan Ball Bearing 5V 0.2A 1W 5500RPM 11.4CFM 30dB Flange Mount
PDF
/
Inventory: 7610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic

Technical

Operating Temperature 14~158°F -10°C~70°C
Series EFB
Size / Dimension Square - 50mm Lx50mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 1W
Voltage - Rated 5VDC
Power Rating 1W
Current Rating (Amps) 0.200A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 5500 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 11.4 CFM (0.319m3/min)
Noise 30.0 dB(A)
Voltage Range 4.5V~5.5VDC
Static Pressure 0.167 in H2O (41.6 Pa)

Dimensions

Height 50mm
Length 50mm
Width 10.00mm

Compliance

RoHS Status ROHS3 Compliant
