EFB0424HHD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 40X40X20MM 24V WIRE
PDF
/
Buying Options
Total Price: USD $8.72
Unit Price: USD $8.715872
≥1 USD $8.715872
≥10 USD $8.222517
≥100 USD $7.757098
≥500 USD $7.318013
≥1000 USD $6.90379
Inventory: 1142
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Weight 0.073lb 33.11g
Material - Frame Plastic
Technical
Published 2006
Series EFB
Size / Dimension Square - 40mm Lx40mm H
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 24VDC
Power Rating 1.68W
Current Rating (Amps) 0.070A
Max Power Dissipation 1.68W
Reach Compliance Code unknown
Current Rating 70mA
Approval Agency CE, CSA, UL, VDE
RPM 8200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 9.4 CFM (0.263m3/min)
Noise 30.5 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.354 in H2O (88.2 Pa)
Dimensions
Height 40mm
Compliance
RoHS Status ROHS3 Compliant
