EFB0412HHD-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
40X40X20MM 12V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 2644
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 27 Weeks
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~158°F -10°C~70°C
Published 2015
Series EFB
Size / Dimension Square - 40mm Lx40mm H
Feature Locked Rotor Sensor
Part Status Active
Termination 3 Wire Leads
Power (Watts) 1.2W
Voltage - Rated 12VDC
Power Rating 1.2W
Current Rating (Amps) 0.100A
Approval Agency CE, CSA, UR, VDE
Lifetime @ Temp 70000 Hrs @ 40°C
RPM 8200 RPM
Bearing Type Ball
Fan Type Tubeaxial
Air Flow 9.4 CFM (0.263m3/min)
Noise 30.5 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.354 in H2O (88.2 Pa)
Dimensions
Height 40mm
Length 40mm
Width 20.00mm
Compliance
RoHS Status ROHS3 Compliant
