EFB0405VHD
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN AXIAL 40X20MM BALL 5VDC WIRE
PDF
/
Buying Options
Total Price: USD $13.89
Unit Price: USD $13.893733
≥1 USD $13.893733
≥10 USD $13.107303
≥100 USD $12.365378
≥500 USD $11.665451
≥1000 USD $11.005139
Inventory: 1172
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 40mm
Technical
Static Pressure 0.416 in H2O (103.6 Pa)
Voltage Range 4.5V~5.5VDC
Noise 32.5 dB(A)
Air Flow 10.1 CFM (0.283m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 9000 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 320mA
Reach Compliance Code unknown
Depth 40mm
Max Power Dissipation 1.6W
Current Rating (Amps) 0.320A
Power Rating 1.6W
Voltage - Rated 5VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension Square - 40mm Lx40mm H
Series EFB
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.073lb 33.11g
Package / Case Axial
Mount Flanges
Supply Chain
Factory Lead Time 19 Weeks
