BFB1612L image
Favorite
BFB1612L image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description FAN BLOWER 159X40MM 12VDC WIRE
PDF
/
Inventory: 8226
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Weight 1.3lbs 589.7g
Material - Frame Plastic

Technical

Published 2010
Series BFB
Size / Dimension Rectangular/Rounded - 159mm Lx165mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 9.6W
Current Rating (Amps) 0.800A
Max Power Dissipation 9.6W
Depth 165mm
Reach Compliance Code unknown
Current Rating 800mA
Approval Agency CE, CSA, UL, VDE
Operating Supply Voltage 12V
RPM 1800 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 49.8 CFM (1.39m3/min)
Noise 51.5 dB(A)
Voltage Range 7V~13.2VDC
Static Pressure 0.846 in H2O (210.7 Pa)

Compliance

RoHS Status ROHS3 Compliant
