BFB1224VH-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Blower Ball Bearing 24V 0.7A 16.8W 3100RPM 42.47CFM 57dB Flange Mount
PDF
/
Inventory: 5290
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series BFB
Size / Dimension Square/Rounded - 120mm Lx120mm H
Feature Locked Rotor Protection
Part Status Active
Termination 2 Wire Leads
Power (Watts) 16.8W
Voltage - Rated 24VDC
Power Rating 16.8W
Current Rating (Amps) 0.700A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 24V
Lifetime @ Temp 50000 Hrs @ 40°C
RPM 3100 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 42.5 CFM (1.19m3/min)
Noise 57.0 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 1.840 in H2O (458.3 Pa)
Dimensions
Width 32.00mm
Compliance
RoHS Status ROHS3 Compliant
