BFB1224LE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Blower Ball Bearing 24V 0.13A 3.12W 1700RPM 19.42CFM 42dB Flange Mount
PDF
/
Inventory: 6666
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 34.50mm
Technical
Static Pressure 0.306 in H2O (76.4 Pa)
Voltage Range 14V~27.6VDC
Noise 42.0 dB(A)
Air Flow 19.4 CFM (0.543m3/min)
Fan Type Blower
Bearing Type Ball
RPM 1700 RPM
Operating Supply Voltage 24V
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.130A
Power Rating 3.12W
Voltage - Rated 24VDC
Power (Watts) 3.12W
Termination 2 Wire Leads
Part Status Active
Size / Dimension Square/Rounded - 126mm Lx125mm H
Series BFB
Physical
Material - Blade Plastic
Material - Frame Plastic
Housing Material Plastic
