BFB1224HE-F00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
125X126X34MM 24V DC FAN W/ SPEED SENSOR (TACH)
PDF
/
Inventory: 3751
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Housing Material Plastic
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series BFB
Size / Dimension Square/Rounded - 126mm Lx125mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Termination 3 Wire Leads
Power (Watts) 8.16W
Voltage - Rated 24VDC
Power Rating 8.16W
Current Rating (Amps) 0.340A
Approval Agency CE, CSA, UR, VDE
Operating Supply Voltage 24V
Lifetime @ Temp 50000 Hrs @ 40°C
RPM 2300 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 27.2 CFM (0.762m3/min)
Noise 51.5 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 0.701 in H2O (174.6 Pa)
Dimensions
Width 34.50mm
Compliance
RoHS Status ROHS3 Compliant
