BFB1224GH-A369
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 120X120X32MM
PDF
/
Inventory: 4653
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series BFB
Size / Dimension Square/Rounded - 120mm Lx120mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Termination 3 Wire Leads
Power (Watts) 38.4W
Voltage - Rated 24VDC
Current Rating (Amps) 1.60A
Ingress Protection IP55 - Dust Protected, Water Resistant
Approval Agency CE, cURus, VDE
Lifetime @ Temp 50000 Hrs @ 40°C
RPM 4400 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 60.4 CFM (1.69m3/min)
Noise 65.0 dB(A)
Voltage Range 14V~27.6VDC
Static Pressure 4.094 in H2O (1019.8 Pa)
Dimensions
Width 32.00mm
Compliance
RoHS Status ROHS3 Compliant
