BFB1212VH-TA50
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 120X32MM 12VDC WIRE
PDF
/
Inventory: 4476
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Wire
Housing Material Plastic
Weight 0.65lb 294.84g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2010
Series BFB
Size / Dimension Square/Rounded - 120mm Lx120mm H
Feature Locked Rotor Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Max Operating Temperature 140°C
Min Operating Temperature 14°C
Power (Watts) 17.6W
Voltage - Rated 12VDC
Power Rating 17.64W
Current Rating (Amps) 1.47A
Max Power Dissipation 17.6W
Ingress Protection IP55 - Dust Protected, Water Resistant
Current Rating 1.47A
Approval Agency CE, CSA, UL, VDE
Operating Supply Voltage 12V
Lifetime @ Temp 50000 Hrs @ 40°C
Life (Hours) 50000 hours
RPM 3100 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 42.5 CFM (1.19m3/min)
Noise 57.0 dB(A)
Voltage Range 5.5V~13.8VDC
Static Pressure 1.850 in H2O (460.8 Pa)
Dimensions
Width 32.00mm
Compliance
RoHS Status ROHS3 Compliant
Ratings IP55, Water Resistant
