BFB1212VH-AF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
Blowers 120x120x32mm 12V DC Fan w/ Speed Sensor (Tach)
PDF
/
Inventory: 7296
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 32.00mm
Technical
Static Pressure 1.848 in H2O (460.3 Pa)
Voltage Range 5.5V~13.8VDC
Noise 57.0 dB(A)
Air Flow 42.5 CFM (1.19m3/min)
Fan Type Blower
Bearing Type Ball
RPM 3100 RPM
Lifetime @ Temp 50000 Hrs @ 40°C
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 1.47A
Voltage - Rated 12VDC
Power (Watts) 17.64W
Termination 3 Wire Leads
Part Status Active
Feature Locked Rotor Protection, Speed Sensor (Tach)
Size / Dimension Square/Rounded - 120mm Lx120mm H
Series BFB
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Blade Plastic
Material - Frame Plastic
