BFB1212SH-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Blower Ball Bearing 12V 1.75A 21W 3600RPM 49.67CFM 59.5dB Flange Mount
PDF
/
Inventory: 928
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 32.00mm
Technical
Static Pressure 2.754 in H2O (686.0 Pa)
Voltage Range 5.5V~13.8VDC
Noise 59.5 dB(A)
Air Flow 49.8 CFM (1.39m3/min)
Fan Type Blower
Bearing Type Ball
RPM 3600 RPM
Lifetime @ Temp 50000 Hrs @ 40°C
Operating Supply Voltage 12V
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 1.75A
Power Rating 21W
Voltage - Rated 12VDC
Power (Watts) 21W
Termination 2 Wire Leads
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square/Rounded - 120mm Lx120mm H
Series BFB
Published 2015
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Blade Plastic
Material - Frame Plastic
Housing Material Plastic
