BFB1212HE
RoHS
/
Package /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
FAN BLOWER 125X34.5MM 12VDC WIRE
PDF
/
Inventory: 9401
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Flanges
Weight 0.717lb 325.22g
Material - Frame Plastic
Technical
Published 2005
Series BFB
Size / Dimension Rectangular/Rounded - 125mm Lx126mm H
Feature Locked Rotor Protection
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 2 Wire Leads
Voltage - Rated 12VDC
Power Rating 8.16W
Current Rating (Amps) 0.680A
Max Power Dissipation 8.16W
Reach Compliance Code unknown
Current Rating 680mA
Approval Agency CE, CSA, UL, VDE
Operating Supply Voltage 12V
RPM 2300 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 27.2 CFM (0.762m3/min)
Noise 51.5 dB(A)
Voltage Range 7V~13.8VDC
Static Pressure 0.701 in H2O (174.6 Pa)
Compliance
RoHS Status RoHS Compliant
