BFB1212GH-AF00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
BFB Series 4400 RPM 120 x 120 x 32 mm 60.39 CFM 12 V 3 Wire Ball Bearing Fan
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Weight 0.65lb 294.84g
Material - Frame Plastic
Material - Blade Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Published 2005
Series BFB
Size / Dimension Square/Rounded - 120mm Lx120mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Power (Watts) 39.6W
Voltage - Rated 12VDC
Current Rating (Amps) 3.3A
Approval Agency CE, CSA, UL, VDE
Lifetime @ Temp 50000 Hrs @ 40°C
RPM 4400 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 60.4 CFM (1.69m3/min)
Noise 65.0 dB(A)
Voltage Range 5.5V~13.2VDC
Static Pressure 4.094 in H2O (1019.8 Pa)
Dimensions
Width 32.00mm
Compliance
RoHS Status ROHS3 Compliant
