BFB1212EH-A
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Blower Ball Bearing 12V 2.37A 28.44W 4000RPM 54.58CFM 62dB Flange Mount
PDF
/
Buying Options
Total Price: USD $32.18
Unit Price: USD $32.1816
≥1 USD $32.1816
≥10 USD $29.93496
≥100 USD $26.941411
≥500 USD $24.696153
≥1000 USD $23.199458
≥3000 USD $20.205988
Inventory: 132
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Static Pressure 3.485 in H2O (868.1 Pa)
Voltage Range 5.5V~13.8VDC
Noise 62.0 dB(A)
Air Flow 54.8 CFM (1.53m3/min)
Fan Type Blower
Bearing Type Ball
RPM 4000 RPM
Life (Hours) 50000 hours
Lifetime @ Temp 50000 Hrs @ 40°C
Operating Supply Voltage 12V
Approval Agency CE, CSA, UL, VDE
Current Rating 2.37A
Reach Compliance Code unknown
Max Power Dissipation 28.4W
Power Rating 28.44W
Voltage - Rated 12VDC
Termination 2 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Protection
Size / Dimension Square/Rounded - 120mm Lx120mm H
Series BFB
Published 2010
Operating Temperature 14~140°F -10°C~60°C
Physical
Material - Frame Plastic
Weight 0.65lb 294.84g
Mount Flanges, Wire
Supply Chain
Factory Lead Time 19 Weeks
