BFB1024HH-F00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
DC Blower Ball Bearing 24V 0.55A 13.2W 4000RPM 28.25CFM 55dB Flange Mount
PDF
/
Inventory: 9846
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Mount Flanges, Wire
Weight 0.353lb 160.12g
Material - Frame Plastic
Technical
Operating Temperature 14~140°F -10°C~60°C
Series BFB
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Feature Locked Rotor Protection, Speed Sensor (Tach)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination 3 Wire Leads
Voltage - Rated 24VDC
Power Rating 13.2W
Current Rating (Amps) 0.550A
Max Power Dissipation 13.2W
Reach Compliance Code unknown
Current Rating 550mA
Approval Agency CE, CSA, UL, VDE
Operating Supply Voltage 24V
Lifetime @ Temp 70000 Hrs @ 40°C
Life (Hours) 70000 hours
RPM 4000 RPM
Bearing Type Ball
Fan Type Blower
Air Flow 28.3 CFM (0.792m3/min)
Noise 55.0 dB(A)
Voltage Range 7V~27.6VDC
Static Pressure 1.300 in H2O (323.6 Pa)
Dimensions
Height 94.4mm
Compliance
RoHS Status ROHS3 Compliant
