BFB1024H-R00
RoHS
RoHS compliant
RoHS compliantPackage /
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
Blowers 97x94x33mm 24V DC Fan w/ Speed Sensor (Lock)
PDF
/
Inventory: 9115
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 33.00mm
Technical
Static Pressure 1.000 in H2O (249.1 Pa)
Voltage Range 7V~27.6VDC
Noise 52.0 dB(A)
Air Flow 25.4 CFM (0.711m3/min)
Fan Type Blower
Bearing Type Ball
RPM 3600 RPM
Approval Agency CE, CSA, UR, VDE
Current Rating (Amps) 0.400A
Voltage - Rated 24VDC
Power (Watts) 9.6W
Termination 3 Wire Leads
Part Status Active
Feature Locked Rotor Sensor
Size / Dimension Rectangular/Rounded - 97.2mm Lx94.4mm H
Series BFB
Physical
Material - Blade Plastic
Material - Frame Plastic
